Cable gland washers provide critical sealing and vibration resistance for industrial cable entries. Engineered to maintain ingress protection (IP66, IP68, IP69K) across enclosures and machinery, our washers prevent moisture, dust, and chemical ingress in demanding operational environments. Available in standard and custom dimensions for Metric, PG, and NPT thread profiles, backed by ISO 9001 certified manufacturing and strict lot traceability.
Material Integrity:
Formulated from high-grade elastomer and metal compounds resistant to aging, UV exposure, and hydrocarbons.
Positive Sealing Structure:
Precision-molded profiles distribute clamping force evenly to eliminate leakage paths around the thread shank.
Vibration Dampening:
Absorbs mechanical shock, preventing cable glands from loosening under continuous machine vibration.
Thermal Stability:
Compounds engineered to maintain elasticity and sealing performance across wide temperature extremes.
Thread Standards: Metric (M12 to M63), PG (PG7 to PG48), NPT (1/4" to 2"), and G threads.
Material Options: EPDM, NBR (Nitrile), Silicone, Neoprene, PTFE, Nylon, and Stainless Steel (304/316).
Operating Temperature:
EPDM: -40°C to +120°C
Silicone: -60°C to +200°C
NBR: -30°C to +100°C
Ingress Protection: Up to IP68 (5 bar / 1 hour) and IP69K certified when paired with matched cable glands.
Compliance & Standards: ISO 9001 facility, RoHS, REACH, UL 94 V-0 (select silicone grades), and CE compliant.
Flat Washers vs. O-Rings:
Flat gaskets for face sealing against enclosure walls; O-rings for groove seating under gland entry threads.
01
Thickness Range:
Standard thicknesses from 1.0 mm to 3.0 mm; custom gauges available.
02
Color Coding:
Standard black and white; custom colors available for circuit tracing or identification.
03
Specialty Compounds:
Low-smoke zero-halogen (LSZH) and oil-resistant synthetic rubbers for railway and marine applications.
04
Electrical Control Panels:
LV/MV distribution boards and automation PLC cabinets.
Industrial Machinery:
CNC machine tool housings, robotics, and automated production lines.
Outdoor Enclosures:
Telecom junction boxes, solar inverter cabinets, and street lighting control units.
Process Industries:
Chemical processing plants and marine deck equipment requiring corrosion-resistant seals.
Supported by in-house compound mixing and CNC precision die-cutting/injection molding tooling:
Process Standard:
Manufactured under ISO 9001 quality management systems with full batch traceability.
01
Dimensional Inspection:
Optical comparators verify inner/outer diameters and thickness tolerances within ±0.05 mm.
02
Material Testing:
Batch testing for tensile strength, elongation at break, and durometer hardness.
03
Sealing Verification:
Hydrostatic pressure testing and air decay leak testing conducted on sample lots.
04
Documentation:
Material Test Reports (MTR), UL compliance data, and RoHS/REACH certificates provided upon request.
05
To receive a formal quotation, please provide the following details:
Product Specification: Part number or material type (e.g., EPDM, Silicone).
Thread Size & Dimensions: Inner diameter, outer diameter, and thickness.
Quantity: Annual volume or per-order batch quantity.
Application Requirements: Operating temperature range, chemical exposure, or required IP rating.
Special Requests: Custom packaging, certificates of analysis, or specific delivery timelines.
As one of the most professional cable gland washers suppliers in China, we're featured by quality products and good service. Please rest assured to buy customized cable gland washers from our factory. Contact us for more details.
