Industrial cable gland locknuts secure threaded cable entries, fittings, and connectors to enclosures, control panels, and machinery bodies. Designed for electrical and mechanical applications, these locknuts maintain tight mechanical fixation under continuous machine vibration, preventing connector backing-out or shifting in harsh operational environments.
Thread Precision:
Manufactured to standard metric (ISO 965 / 6H tolerance class), PG, NPT, and G thread tolerances, ensuring smooth engagement with cable glands and conduit fittings without cross-threading.
Corrosion Protection:
Base materials undergo strict passivation (stainless steel) or electro-galvanized/controlled nickel plating (minimum 3–5 $\mu m$ coating thickness) to resist oxidation in humid, saline, or chemical environments.
Anti-Vibration Design:
Integrated biting edges, surface serrations, or flange profiles grip enclosure walls firmly to prevent loosening caused by industrial vibration or thermal cycling.
Load Distribution:
Flat parallel bearing surfaces distribute tightening torque evenly, avoiding localized stress concentrations on thin-sheet metal enclosures.
Thread Standards: Metric (M12 to M63, 6H grade), PG (PG7 to PG48), NPT (3/8" to 2"), G (PF).
Materials: Brass with Nickel Plating, Stainless Steel (AISI 304 / AISI 316), Polyamide 66 (PA66).
Operating Temperature:
Metal types: -40°C to +100°C (up to +200°C with high-temp seals).
Plastic types: -20°C to +80°C.
Ingress Protection (IP): Contributes to system IP rating up to IP68 when paired with proper sealing washers and cable glands.
Compliance: RoHS, REACH, CE.
Material Finishes:
Bright nickel-plated brass (with certified 3–5 $\mu m$ plating) for standard indoor panels; marine-grade 316 stainless steel for offshore, marine, and chemical processing; flame-retardant PA66 nylon (UL94 V-2 / V-0) for lightweight or insulated applications.
Thread Variations:
Fine pitch metric threads, extra-deep profiles for thick-walled plastic or cast aluminum enclosures, and specialized inch-based threads.
Locking Configurations:
Standard hex profile, knurled exterior for tool-free hand tightening, and flanged versions with built-in tooth washers.
Electrical Control Cabinets:
Securing power and control cable entries on industrial automation switchboards.
Machinery & Robotics:
Fastening sensor and actuator lines on automated assembly lines subject to continuous movement and vibration.
Outdoor Distribution Boxes:
Outdoor utility housings, telecom pedestals, and solar inverter junction boxes requiring weather-resistant fastening.
Process Equipment:
Food processing, pharmaceutical, and wastewater treatment machinery requiring washdown-resistant hardware.
Non-Standard Threads:
Custom thread pitches, oversized diameters, or imperial-to-metric conversion threads machined to drawing specifications.
Material Selection:
Special alloy grades (e.g., brass alloys, specific stainless steel grades) sourced for extreme chemical exposure.
Laser Marking:
Custom branding, batch codes, or thread size labeling laser-etched directly onto flat faces.
Packaging:
Bulk industrial bagging, compartmentalized kit boxes, or custom barcoded retail packaging for distributors.
Production Capacity:
High-speed automatic CNC turning and cold-forming lines ensure consistent output of millions of pieces per month with stable batch-to-batch tolerances.
Dimensional Inspection:
100% optical sorting and profile projector checks verify thread pitch diameter (meeting ISO 6H gauges), inner/outer diameter, and thickness against ISO standards.
Torque & Tensile Testing:
Random sampling tested on automated torque test benches to verify resistance to stripping and thread shear under over-tightening conditions.
Material & Coating Verification:
Spectrometer material composition analysis and micro-section coating thickness checks performed on every raw material batch; mill test certificates (MTC / EN 10204 3.1) available upon request.
To receive a prompt and accurate commercial offer, please provide the following details:
Product Model / Type: (e.g., Nickel-Plated Brass Metric Locknut)
Thread Specification: (e.g., M20 x 1.5 - 6H, PG13.5, or NPT 1/2")
Material Requirement: (Nickel-Plated Brass / Stainless Steel 304 / Stainless Steel 316 / PA66)
Required Quantity: (Annual volume or per-batch order quantity)
Special Requirements: (Custom thickness, specific packaging, or material test certificates)
As one of the most professional cable gland locknuts suppliers in China, we're featured by quality products and good service. Please rest assured to buy customized cable gland locknuts from our factory. Contact us for more details.
