Nylon Gland Sealing Washer
Nylon Gland Sealing Washers (also specified as cable gland gaskets or flat sealing rings) provide reliable secondary static sealing between cable gland male threads and enclosure entry ports. Designed to maintain continuous compressive stress against environmental elements, these virgin PA66 washers ensure dust-tight and watertight integrity in industrial electrical installations.
Nylon Gland Sealing Washers | Technical Specifications & Sourcing Guide
Nylon Gland Sealing Washers (also specified as cable gland gaskets or flat sealing rings) provide reliable secondary static sealing between cable gland male threads and enclosure entry ports. Designed to maintain continuous compressive stress against environmental elements, these virgin PA66 washers ensure dust-tight and watertight integrity in industrial electrical installations.
Key Features
Virgin Polymer Structure: Molded exclusively from high-grade Polyamide 6.6 (PA66) resin, delivering optimal tensile strength and resistance to ambient fatigue.
Balanced Force Distribution: Precision-cut flat geometry spreads clamping torque evenly, preventing localized deformation or point-stress fracturing on panel walls.
Enclosure Ingress Protection: Complements O-ring or standard cable entries to sustain system protection ratings up to IP68 when properly torqued against flat surfaces.
Wide Thermal Range: Maintains mechanical and sealing performance across continuous operating temperatures from -40°C to +100°C (short-term tolerance up to +120°C).
Technical Specifications
|
Parameter |
Technical Data |
|
Thread Compatibility |
Metric (M12 to M63), PG (PG7 to PG48), NPT, G (PF) |
|
Standard Material |
Virgin PA66 (UL94 V-2 flammability rating; V-0 available on request) |
|
Standard Color |
Natural White / Industrial Black (UV-stabilized compound) |
|
Operating Temperature |
-40°C to +100°C (Continuous) |
|
Chemical Resistance |
Resistant to mineral oils, greases, diesel fuel, mild acids, and common alkaline solvents |
|
Regulatory Compliance |
RoHS, REACH, Halogen-Free, CE compliant |
Product Options & Configurations
Metric Series: M12 x 1.5 through M63 x 1.5 (Standard thicknesses: 1.0 mm to 2.0 mm).
PG Series: PG7 through PG48 designed for legacy and export-oriented machinery.
Material Variations:
Standard Natural PA66: Ideal for sheltered indoor industrial control environments.
UV-Stabilized Black PA66: Formulated for outdoor solar combiner boxes and utility enclosures.
Flame-Retardant PA66 (UL94 V-0): Specified for railway, rolling stock, and transit infrastructure.
Typical Applications
Electrical & Automation Cabinets: PLC enclosures, low-voltage switchgear, and industrial control panels.
Junction & Distribution Boxes: Outdoor electrical junction points requiring long-term weatherproofing.
Heavy Machinery (OEM): Machine tool wiring entries exposed to cutting fluids, coolants, and constant mechanical vibration.
Renewable Energy Systems: Photovoltaic solar inverter housings and wind turbine nacelle control units.
OEM & ODM Customization Capabilities
Custom Dimensions: Non-standard inner diameters (ID), outer diameters (OD), and thickness profiles manufactured to drawing tolerances via precision injection molding or automated blanking.
Pigmentation Control: Custom color matching available for complex circuit identification or brand aesthetics.
Industrial Packaging Options: Bulk industrial bagging, compartmentalized hardware kits, or private-label barcode labeling for distributor and OEM assembly lines.
Manufacturing & Quality Control
Incoming Resin Verification: Raw PA66 batches undergo Melt Flow Index (MFI) and moisture content analysis prior to processing.
Dimensional Inspection: Automated optical sorting and periodic profile projector checks maintain strict ID, OD, and thickness tolerances (+/-0.1 mm).
Lot Traceability: Master cartons feature permanent batch labeling linked to downloadable Material Test Reports (MTR) and compliance documentation.
Frequently Asked Questions
Q: How do I select the proper washer size for my cable gland?
A: Match the inner diameter (ID) of the washer directly to the nominal thread size of the cable gland (e.g., an M20 x 1.5 gland requires an M20 washer). Ensure the outer diameter (OD) provides full coverage over the enclosure knockout hole.
Q: Can standard natural white washers be used outdoors?
A: Standard natural PA66 lacks UV stabilizers and may embrittle under direct sunlight over extended periods. For outdoor applications, specify UV-stabilized black PA66.
Q: What is the continuous operating temperature range?
A: Standard PA66 material maintains structural stability and sealing elasticity from -40°C to +100°C.
Q: Are test reports and compliance certificates provided?
A: Yes. RoHS, REACH declarations and Material Test Reports (MTR) are available upon request for every production batch.
Q: What is the standard minimum order quantity (MOQ)?
A: Stock standard sizes start at an MOQ of 1,000 pieces per SKU. Custom tooling or non-standard dimensions are subject to evaluation.
Q: What are the standard production lead times?
A: In-stock standard configurations ship within 3 to 5 business days. Custom molded specifications typically require 15 to 20 business days.
Request a Quote
To streamline your RFQ, please include the following technical requirements:
Thread Standard & Size: (e.g., Metric M20 x 1.5 or PG16)
Material Specification: (Standard PA66, UV-Black, or V-0 Flame Retardant)
Required Quantity: (Batch volume / Projected annual usage)
Documentation Needs: (MTR, RoHS/REACH compliance certificates)
